Drawbar-ZD 13.5-1, rigid drawbar eye Ø 40 mm Total len. 3500 mm

Drawbar-ZD 13.5-1, rigid drawbar eye Ø 40 mm Total len. 3500 mm

400431519

⚖️ 149,4 kg

Login view prices

Description

Drawbar ZD 13.5-1, rigid, drawbar eye Ø 40 mm, to DIN 74054-40 and EC 94-20 Class S. EC no. e4*94/20*0956*00, for central axle trailers (over 25 km/h) 13.5 t permissible gross weight, permissible drawbar load 1000 kg, free drawbar length: 2300 mm, drawbar eye: DIN 74054-40 D, V value 32.0 kN, Dc value 90 kN,

Attributes

Coupling type Drawbar eye 40 mm
Height 160.0
Length 3500.0
Perm punkt support load 1000.0
Perm punkt total weight 13500.0
Tube shape Square tube
Width 160.0

Product safety

Note in accordance with Regulation (EU) 2023/988 on general product safety: The responsible economic operator within the meaning of the Regulation is Suer Nutzfahrzeugtechnik GmbH & Co. KG, Handelsstraße 5, 42929 Wermelskirchen, Germany. For safety-related enquiries or notifications in connection with our products, please contact: produktsicherheit@suer.de.
