Drawbar ZD 10-1, rigid, drawbar eye Ø 40 mm, total len. 2900 mm

Drawbar ZD 10-1, rigid, drawbar eye Ø 40 mm, total len. 2900 mm

400431513

Drawing no: 51.31.10 0100

⚖️ 147,5 kg

Price on request

Description

Drawbar ZD 10-1, rigid, drawbar eye Ø 40 mm, total length 2900 mm, to DIN 74054-40 and EC 94-20 Class S. EC no. e4 *94/20* 0872*00, for central axle trailers (over 25 km/h) 10 t permissible total weight, permissible drawbar load 1000 kg, V-value 30.8 kN, Dc-value 70 kN, dimension FL 1700 mm, towing eye complies with DIN 74054-40 D

Attributes

Coupling type Drawbar eye 40 mm
Height 140.0
Length 2900.0
Perm punkt support load 1000.0
Perm punkt total weight 10000.0
Tube shape Square tube
Width 140.0
